Description
AVR MARATHON DVR2000E
Bộ điều áp tự động kỹ thuật số Avr Marathon DVR2000E (Enhanced Digital Technology DVR2000E Voltage Regulator)
Advanced Features:
DVR2000E True RMS Sensing – One or Three Phase
Connect sensing mode you prefer. The DVR2000E Senses 95 to 600 volts ±10% at 50/60 hertz. Patented circuitry senses true RMS voltage rather than average for superior load regulation.
DVR2000E Soft-Start Ramp on Initial Start-Up
Controlled increase to rated voltage. Limits overshoot of voltage during voltage build-up.
DVR2000E Engine Unloading:
Monitors rate of frequency change during transient conditions. Provides additional voltage dip during speed drop to allow engine to recover faster.
DVE2000E Overvoltage Shutdown:
Provides generator protection during sustained overvoltage. The overvoltage point is preset at 20% over normal generator operating voltage, with a preset timeout of 0.75 seconds.
DVR2000E VAR/PF Controller:
Model DVR®2000EC (optional) provides control when paralleled to utility power. VAR or PF control can be selected or changed by regulator adjustment.
DVR2000E Encapsulated Design:
Maximum protection against moisture or abrasive contamination, which can lead to early regulator failure. Tested to MIL-STD-705, Method 711.1C. Salt fog tested to MIL-STD-810E.
DVR2000E Auto/Manual Mode:
Exciter field current controlled by the regulator or manually set at a fixed value.
Marathon DVR2000E Voltage Regulator Product Description:
| True RMS Sensing ± One or Three Phase |
|
| Soft-Start Ramp on Initial Start-Up |
|
| Engine Unloading |
|
| Over voltage Shutdown |
|
| VAR/PF Controller |
|
| Encapsulated Design |
|
| Auto/Manual Mode |
|
